24V DC 32 Tone Platform Base Sounder Beacon White Red Lens
1100-0641- Combined platform sounder/beacon
- Provides 360° visibility via its high intensity LED array with a flash rate of once per second
- 32 tones
- Supplied with a clear lens but other colours are available, red, amber or blue
- Can accommodate the Firesafe range of detectors and most other leading detector brands
- Cover plate is also available, allowing product to be converted into a stand alone sounder beacon
Show more
Specifications
| Colour | White |
|---|---|
| Current Consumption Range | 8 - 11.5mA |
| Decibel Rating | 88.5 - 94.8 dB[A] @ 1 m |
| Depth | 34.5mm |
| Dimensions | (H)116 mm x (W)116 mm x (D)34.5 mm |
| Guarantee | 1 Year |
| Height | 116mm |
| IP Rating | IP21 |
| Lens Colour | Red |
| Logistics Partner | NONE |
| Material | ABS Fire Retardant Plastic |
| Number Of Tones | 32 |
| Operating Frequency | 440 - 2900Hz |
| Packaging Types | Each |
| Similar Stock | No |
| Size | 116 mm x 34.5 mm |
| Standards | BS 5839 |
| Temperature Range | -20 - +70°C |
| Type | Sounder Beacon |
| Unspsc V13 | 46191505 |
| Unspsc V18 | 46191505 |
| Unspsc V22 | 46191505 |
| Unspsc V24 | 46191505 |
| Voltage Range | 18 - 30 Vdc |
| Volume Control | Yes |
| Weight | 0.27kg |
| Width | 116mm |
