1.5mm² 2C+E Enhanced Fire Cable Red (500m Drum)
1633-2142- Enhanced is approved and certified by LPCB & BASEC to fully meet the requirements of 'Enhanced' fire cables for use with UK fire systems.
- Produced using the latest technology, materials and equipment
- Every detail from start to finish is recorded and traceable, a quality batch and test number is printed on every reel, and time and date of manufacture printed along the entire length of the cable
- Easy to install and superb working flexibility, stays where you put it
- Up to 12 twists per metre for Data Protection
- Copper/ Co-polymer foil screen
- Low smoke and zero halogen
Show more
Specifications
| Available Options | Other colour sheaths are available to order |
|---|---|
| Colour | Red |
| Compliance | BASEC, LPCB |
| Core Colours | Brown and Blue |
| Cross Sectional Area | 1.50mm² |
| Dimensions | (L)500 m |
| External Diameter | 8.2mm |
| Flame Retardent | Yes |
| Guarantee | 10 Years |
| Length | 500m |
| Logistics Partner | NONE |
| Material | Copper/Co-polymer Foil Screen |
| Number Of Cores | 2+E |
| Packaging Types | Reel |
| Sheath | Low Smoke Halogen Free Thermoplastic |
| Similar Stock | No |
| Standards | BS 5266-1:2011, BS 5839-8:2013, BS 5839-9:2013, IS 3218:2009/AC:2010, IS 3217:2008 |
| Suitable For | Zone 1 and Zone 2 Hazardous Area use, Air Conditioning, Computer Control & Lift |
| Unspsc V13 | 26121640 |
| Unspsc V18 | 26121640 |
| Unspsc V22 | 26121640 |
| Unspsc V24 | 26121640 |
| Voltage Rating | 500V 300V |
| Weight | 0.098kg |
