Door Monitoring Point with Button Reset
0017-1199- Button reset option
- Isolatable, used to protect doors to generate an alarm on the system
- Requires 1 gang 25mm depth backbox [plastic round cornered or metal flushing box]
Show more
Specifications
| Colour | Grey |
|---|---|
| Compliance | CE |
| Depth | 35mm |
| Dimensions | (H)87 mm x (W)87 mm x (D)35 mm |
| Height | 87mm |
| Humidity Range | Up to 95% RH (Non Condensing) |
| IP Rating | IP45 |
| Indication | Yes |
| Logistics Partner | NONE |
| Material | Plastic |
| Mounting | Wall |
| Operating Temperature Range | -5 - 40°C |
| Packaging Types | Box |
| Similar Stock | No |
| Type | Isolatable Monitoring Point |
| Unspsc V13 | 46171604 |
| Unspsc V18 | 46171604 |
| Unspsc V22 | 46171604 |
| Unspsc V24 | 46171604 |
| Voltage Rating | 230V |
| Weight | 0.1kg |
| Width | 87mm |
