4 Zone Call Controller
0017-1280- Mute/reset button
- Requires 12V PSU
- An attractively-designed four zone call controller c/w mute and reset buttons
- Fully compatible with entire range of 800 series call system components
- Capable of indicating standard [constant tone] and emergency [intermittent tone] calls
- Requires a separate NC930 12V 250mA PSU
- Includes four zonal alarm LEDs, reset and mute buttons
- Two open collector outputs [emergency and aux out]
- Up to two NC944s can be connected to one NC930 PSU to create a mini-call system of up to 8 zones
- Mounts on a standard 25mm UK double gang back box
Show more
Specifications
| Available Options | Optional NC941B battery back up kit available for use with the NC930 12V 250mA PSU |
|---|---|
| Colour | Grey |
| Compliance | CE |
| Depth | 21mm |
| Dimensions | (H)87 mm x (W)147 mm x (D)21 mm |
| Guarantee | 1 Year |
| Height | 87mm |
| Humidity Range | Up to 95% RH (Non Condensing) |
| IP Rating | IP41 |
| Indication | Yes |
| Logistics Partner | NONE |
| Material | Plastic |
| Operating Temperature Range | -5 - 40°C |
| Packaging Types | Box |
| Similar Stock | No |
| Type | Four Zone Call Controller |
| Unspsc V13 | 46171604 |
| Unspsc V18 | 46171604 |
| Unspsc V22 | 46171604 |
| Unspsc V24 | 46171604 |
| Voltage Rating | 230V |
| Weight | 0.15kg |
| Width | 147mm |
